Visual Analyser is a comprehensive professional real-time software suite that transforms your PC into a full set of measurement instruments, with no additional hardware required (you can use your PC’s sound card). Alternatively, you can use specific external hardware (see the Hardware section for an example). Visual Analyser runs on Windows operating systems. The Visual Analyser 25 Silvia edition is now available (for both 64-bit and 32-bit platforms), though it is no longer compatible with Windows 9x. VA also runs on Linux through the wine utility. Wave, MP3, and FLAC file management were added in the 2012 version and have been further improved in the 25 versions. VA has been adopted as the basic measurement software by Nuova Elettronica magazine (a famous italian magazine that has now ceased all publication).

The VA 25 Silvia edition features a new 3D interface, an improved spectrum analyzer, a graphic equalizer, playback and recording tools, a frequency response tool, an updated menu, the ability to capture samples from other applications in real time, and much more.




See also DEMOCRATIC HELP and download my latest Ph.D. thesis (only Italian, sorry)

VA on YOUTUBE!

The latest versions (25, 2022, 2021, 2020, 2019, 2014, 2012, 2011, and the 2010 NE-XT v2.4) include a powerful ZRLC meter (updated from 2019 onwards) capable of measuring the impedance of a device across various frequencies, including capacitance, inductance, resistance, real and imaginary components, Q-factor, and phase. This feature requires an acquisition board (such as a sound card) and a simple circuit utilizing two low-cost operational amplifiers, with an example available on this website. The ZRLC software also supports measuring the input impedance of amplifiers, transformers, and loudspeakers—see ZRLC details for more information. A simple vector scope has been added alongside the ZRLC meter window, and a full screenshot is available here. The recent 2.4 version introduces new and exciting features, highlighted in the News section. The magazine Nuova Elettronica has also published an article detailing specific hardware for the ZRLC function. Last but not least,an article on Elsevier.

Note to all VA website visitors: The content of the Italian website may differ from the English version. It is not just a simple translation, as there are different links to Italian articles and authors (which may not be relevant to English readers). Additionally, some minor details differ due to my better proficiency in the Italian language!

Main characteristics of VA:

VA is a real-time program that simulates a range of electronic instruments, including:

  • Oscilloscope (dual channel, xy, time division, trigger);

  • Spectrum Analyzer with amplitude and phase display (linear, log, lines, bar, octaves band analysis 1/3, 1/6, 1/9, 1/12, 1/24);

  • Wave-form generator with "custom functions", triangular, square, sinusoidal (all with NO ALIASING and smooth transition), white/pink noise, pulse generation, DC generation[New!];

  • Frequency meter (in time and frequency domain) and counter; in time domain by means of a real time zero crossing algorithm;

  • Volt meter with DC[New!], true RMS, peak to peak and mean display plus resolution calculus;

  • Filtering (low pass, hi pass, band pass, band reject, notch, "diode", DC removal, graphic equalizer;

  • Memo windows (data log) for analysis and storage of time series, spectrum and phase  with "triggering" events; THD and Impedance data logging with spline interpolation; possibility to save the graphics in various format (.tee, .txt, .wmf) )and display them with an internal viewer[New!];

  • Screenshot of Spectrum and Scope window;

  • A TRUE software digital analog conversion (for complete signal reconstruction using Nyquist theorem) ;

  • Frequency compensation: possibility to create/edit a custom frequency response and  add it to the spectrum analyzer computed spectrum; added standard weighting curves A,B,C [New!]in parallel with custom frequency response;

  • Support for 8/16/24 bit soundcard by means of API calls;

  • Internal 80 bit IEEE floating point variables for minimum rounding error;

  • Unlimited frequency sampling (depend from the capabilities of your soundcard/acquisition device);

  • Cepstrum analysis;

  • Cross Correlation;

  • Extended THD measurements, with automatic sweep, compensation, data log;

  • ZRLC-meter with Vector scope, automatic sweep in time and frequency for automatic measurement;[New!]

  • Calibration mechanism (you can calibrate the VA scales directly in VOLT or dB or percent full scale) ;

  • Set of values computed in real time (peak to peak, peak, crest factor, form factor, true rms, mean, frequency with zero-crossing algorithm);[New!]

  • Wave/flac/mp3 file recording and playback;

  • Internal input;

  • Custom FIR filters;

  • Graphic equalizer;

  • Acquires audio samples from other applications;

  • Tool for automatic computation of frequency response of device (amplifier, louspeaker etc. for now only two simple methods, but soon MLS and ESS);

  • Automatic Check for new version of VA (main menu, help item).



See the Product details section for more details or here for a brief introduction.

ROGA-Instruments Roga adopted Visual Analyser as a basic tool for its products for several years (example ROGAdaq2).
